产品详情
特点∶
1、自动洗胃机由气泵、控制管路、控制电路、机箱组成;
2、洗胃机采用压力传感器、流量传感器和计算机单板机控制， 实时动态参数液晶显示，实现了洗胃的自动化;
3、液晶屏自动显示洗胃压力、进出液量、洗胃状态和洗胃次数;
4、进入洗胃状态后自动记录洗胃次数，且当洗胃次数达到设定的洗胃次数时自动停机;
5、大通径管路进出，确保不会堵塞;
6、设有紧急出胃功能，当洗胃出现进多出少时，可按此键吸出多余污液;
7、进、出胃压力、液量可根据不同的患者需要任意设置;
8、全塑外壳，美观大方;
9、压力绝对值在47kPa～67kPa范围中;
10、工作环境∶ 温度∶+5℃～+40℃，相对湿度∶ 25℃不超过80%，大气压力∶86KPa～ 106KPa;
11、洗胃机按防电击类型及程度分类为Ⅰ类设备B型应用部分，运行模式为连续运行，IPX0、非AP型或APG型普通设备;
12、产品符合GB9706.1、YY0505相关要求。
技术指标∶
1、电源∶ AC220V±22V，50Hz±1Hz;
2、输入功率∶≤140VA;
3、进胃压力设置∶≤0.067MPa;
4、出胃压力设置∶ ≥-0.067MPa;
5、进胃液量设置∶ ≤350ml/次;
6、出胃液量设置∶≤450ml/次;
7、进出胃时间∶ ≤30s/次。
选配
FEATURES:
1、Automatic paunch flusher is constitute of air pump, control pipeline, control circuit and case.
2、The stomach washing machine is controlled by pressure sensor. flow sensor and computer single-board machine
3、The LCD screen automatically displays the pressure of gastric lavage, in and out liquid quantity,gastric lavage condition,gastric lavage times.
4、When in gastric lavage condition, auto access to gastric lavage and when the number of gastric lavage reaches the set number of gastric lavage, the machine stops automatically.
5、The strong dint change to defend to block up the structure and big path tube roads to pass in and out, insure will not stop.
6、It is equipped with the function of emergency gastric outlet. When the stomach is washed,the excess sewage can be sucked out by pressing this key.
7、Get in and out lavage pressure, the fluid volume can be arbitrarily set according to the needs of different patients.
8、Full plastic shell, beautiful and generous.
9、The absolute value of pressure is in the range of 47Kpa~67 Kpa.
10、Work Environment:temperature;+5°C～+40°C.Relative humidity:≤80%(25°C ), Atmospheric pressure:86Kpa~106 Kpa
11、According to the type and degree of electric shock prevention, the gastric lavage machine is classified into l type equipment
and B type application part, The running mode is continuous operation,IPXO,Not AP type and APG type common equipments.
12、This machine meet the related requirement of IEC60601-1、IEC60601-1-2.
TECHNIQUE:
1、Power supply: AC220V±22V, 50Hz±1Hz;
2、Input: ≤140VA;
3、Get into gastric pressure stting: ≤0.067MPa;
4、Get into gastric pressure stting: ≥-0.067MPa;
5、Get into gastric pressure setting: ≤350ml/every time;
6、Get out gastric pressure setting: ≤450ml/every time;
7、Get in and out gastric time: ≤30s/every time.
